Power: 4.000 kN
Energy at 30 rpm: 25,4 kJ
Strokes/min: 5-60 1/min
Stoke (fixed): 280 mm
Ram adjustement: 150 mm
Shutheight: 620 mm (stroke down, adjustment up)
Size of bolster: 1.150 x 1.100 mm
Size of ram: 1.150 x 1.000 mm
Weight: app. 32.000 kg
Equiped by:
- hydraulic overload
- pneumatic clutch - brake - combination
- motoriced ram adjustement
- pneumatic ram balancing system
- photocells in front
option:
die - cushion, stress-control, anti vibration machine feet
Maschinen sind mechnaisch fertig, Elektrik muss vervollstaendigt werden.
