PRELIMINARY SPECIFICATIONS - SUBJECT TO VERIFICATION:
AGE (APPROXIMATE) .............................. 2007
WORLD CLASS AEROSPACE PROFILE MACHINING CAPABILITY
MAXIMUM FLEXIBILITY FOR 6-SIDED PROFILE MACHINING
FEATURES MAXIMUM FLEXIBILITY AND GREAT COST EFFECTIVENESS IN
MACHINING ALUMINIUM AND STEEL.
A FLEXIBLE CLAMPING SYSTEM FOR MACHINING DIFERENT PROFILE CROSS
SECTIONS AND UP TO 14 TOOL SLOTS ALLOWS FOR A WIDE RANGE OF
APPLICATIONS UP TO 6 METRES IN LENGTH.
AN INTEGTRATED SAWING UNIT FOR SPATIAL CUTS COMPLETES THE HIGHLY
EFFICIENT PBZ-NT MACHINE CONCEPT.
5-AXIS CONCEPT
6-SIDED MACHINING COMPLETE FROM BAR STOCK UP TO 6 METERS/ 255"
FIXED PORTAL
X-AXIS TRAVEL: 255"
Y-AXIS TRAVEL: 29.5"
Z-AXIS TRAVEL: 11.8"
ROTATIONAL ANGLE:
A-AXIS +/- 120 DEG.
C-AXIS +/- 200 DEG.
PART LENGTHS UP TO 6 METRES/ 255" IN ALUMINUM & STEEL
WORKPIECE CROSS SECTION MAX. 300 X 300 MM (WXH)
SPINDLE MOTOR 25 H.P., 28,000 RPM
CNC CONTROLLED CLAMPING SYSTEM, VARIABLE NUMBER OF CLAMPING JAWS
AUTOMATIC POSITIONING OF CLAMPING VISES
SAW BLADE DIAMETERS UP TO 500 MM
TOOL CHANGER: DISC TYPE TOOL MAGAZINE MAX. 14 SLOTS
