60,000 operating hours
Spindle 24,000 hour single shift
Control: Heidenhain TNC 426 contouring control (latest software version)
travels
X axis 1250 mm
Y-axis 880 mm
Z-axis 880 mm
Rapid traverse 24 m / min
Feed speed: 10,000 mm / min
Speed range 0-12000 rev / min
Spindle power: 15 kW
NC rotary table - 1250x1000 mm
Tool magazine - 30 times
Tool: SK 40
Mode 3 +4
Controlled milling head (b-axis)
electronic handwheel
3-D probe
Coolant system
chip conveyor
3 pcs. Levelling elements
transporter rick
operating Instructions
Full protection cabin with sliding doors and interior lighting
