Biggest Radteilkreisdurchmesser
In Translation 1: 1: 200 mm
In Translation 1: 7.5: 280 mm
smallest Radteilkreisdurchmesser
In Translation 1: 1: 25 mm
In Translation 1: 7.5: 20 mm
Largest Teilkegellaenge: 143 mm
Biggest transmission ratio: 1: 7.5
Biggest module: 8
Largest Zahnlaenge: 70 mm
Biggest Slide stroke: 80 mm
Stoesselhubzahlen (8): 60 - 300 min-¹
Turn machine drive: 450 min-¹
Width of the pulley: 100 mm
Hole in the dividing head spindle: 135 mm
Power consumption of the machine: 3,1 kW
Dimensions of machine LxWxH: 3.00 x 2.20 x 2.00 m
Machine weight: 3,000 kg
