Shaft Ø: 105mm
Number of rolls: 3
Stroke X-Axis: 390mm
Resistance moment:3000 NmCM³
Capacity flat: 120 x 15 x R-1200mm
Capacity Tube: 114 x 6,3 x R-1200Ø x mm
Capacity bar: 80 x 80 x R-1400mm
Capacity T-Profile:100 x 100 x 10 x R-1600mm
Working speed: 1 -16.000mm/min.
Length: 2100mm
Width: 1860mm
Height: 1420mm
Weight: 2300kg
Specifications:
Shaft Ø: 105mm
Number of rolls: 3
Stroke X-Axis: 390mm
Resistance moment:3000 NmCM³
Capacity flat: 120 x 15 x R-1200mm
Capacity Tube: 114 x 6,3 x R-1200Ø x mm
Capacity bar: 80 x 80 x R-1400mm
Capacity T-Profile:100 x 100 x 10 x R-1600mm
Working speed: 1 -16.000mm/min.
Length: 2100mm
Width: 1860mm
Height: 1420mm
Weight: 2300kg
