Table diameter 4200 mm
Max swing 9000 mm
Max swing, to reach center 6000 mm
Max turning height 3600 mm
Vertical support on crossrail, tilting 35/ 10 Degree
Vertical travel 1800 mm
Horizontal travel 3200 mm
Horizontal support
Vertical travel 3600 mm
Horizontal stroke 1500 mm
Table speeds 0,47-38 rpm
Table capacity 90 000 kg
Table motor 90 kW
Column travel 1500 mm
Crossrail, Vertical travel 3300 mm
Machine weight 135 000 kg
