Diameter of working spindle: 150 mm
X-axis travel: 15 000 mm
Y-axis travel: 4 000 mm
Z-axis travel: 1 000 mm
W-axis travel: 800 mm
Taper in spindle: ISO 50
Rotation of spindle: 10-2500 rpm
Main spindle input: 51 kW
Control system Heidenhain iTNC 530.
Specifications:
The machine is under power, possible to test.
Automatic tool changer - 40 positions
Universal milling head included.
Cooling through spindel - CHOV 40 bar
Table dimensions
- Rotary table (max 25 000 kg) 2500 x 3000 mm
- Floorplates UD 4 (4020 x 1885 x 400 mm) 2 pieces
- Floorplates UD 4 (4020 x 1260 x 300 mm) 2 pieces
- Floorplates 4 (3100 x 1600 x 250 mm) 1 piece
