Facing Head, Tooling, 4-axis DRO

SPECIFICATIONS:
TABLE SIZE : ……………………… 23.6” X 35.4”
WORK TABLE SIZE:…………..…… 23.6” x 18” ( DUAL STATION)
TABLE INDEXING SPEED:…...… 4.0 SEC. @ 180 DEGREES
WORK LOAD:……………….……….. 660 LBS.
TRAVELS:…. ‘X’-AXIS:………. 19.68”
‘Y’-AXIS:……….. 11.81”
‘Z’-AXIS:………. 11.81”
FEED RATES:.. RAPID X-Y-Z… 1181 IPM
CUTTING ……… UP TO 393 IPM
SPINDLE SPEEDS:………………… 10 – 8,000 RPM
SPINDLE TAPER:…………………… BT-30
SPINDLE MOTOR:………………… 10 HP / 7.5 HP (30 MIN. / CONT.)
TURRET TOOL CAPACITY:……. 14 TOOLS
TOOL CHANGE TIME:…………… 1.2 SEC. / 2.2 SEC. (T-T / C-C)



EQUIPPED WITH:
** YASNAC J50M CNC CONTROL.
** COOLANT SYSTEM.
** RS-232 PORT.
** TABLE SPLASH GUARD.
** 24” X 36” ALUMINUM FIXTURE PLATE.
** MISC. TOOL HOLDERS (APPROX. 50)
** MACHINE / PROGRAMMING MANUALS.

SERIAL #.......... 45019003
DIMENSIONS:.. 65” (L-R) x 108” (F-B) X 93” HIGH
WEIGHT:……..... 7,700 LBS APPROX.
ELECTRICS:…... 220 VOLTS / 3 / 60
PHOTOS:……..... SEE ATTACHED. OTHERS AVAILABLE.
DEMO:………...... YES

32000
