Table travel X: 3000 mm / 118.1 in
Headstock vertical travel Y: 2500 mm / 98.4 in
Column horizontal travel Z: 1500 mm / 59 in
Spindle Diameter: 130 mm / 5.12 in
Spindle Taper: CAT 50
X,Y,Z on Box ways
Control System: Fanuc 32i
Fanuc Spindle Main Motor Power 30 kW
Hand wheel Fanuc iPendant
Separate Control Panel with 15" LCD Screen
CNC Positioning Rotary Table on a Cross Roller Taper Bearing Max. Load 30,000 lbs,
Table top size 1800 x 2200 mm / 70.86 x 86.61 in
Spindle support 250 mm / 9.8 in
Absolute direct rotary encoder for B-Axis and W
Absolute direct linear scales for X, Y, Z Axes
Air-conditioned distribution box (electro cabinet)
Headstock Oil Chiller unit
Machine capable for UHM/PHM heads
Remote Diagnostics
Operator’s safety shield – fixed, with LED light on the top
Levelling Bolts & Seal Pads
CE Standard with TŰV Certificate, EC Declaration of Conformity, Electro Revision Certificate (safety fence is an option)
UL rated components for electrical cabinet and wiring
Documentation (Operator and Service Manuals; Machine Documentation; Control System Programming, Service and Operator Manuals; Geometric Measuring Documentation) in English
2 days training included
12 months standard guarantee
Packing - Inland and Overseas
DDP customer location
Complete installation by Lucas, A Fermat Group Company
