Spindle Diameter: 110 mm / 4.3 in
X axis - table travel: 3 000 mm / 119 in
Y axis - headstock travel: 2 000 mm / 79 in
Z axis - column travel: 1 250 mm / 49 in
W axis – spindle out travel: 730 mm / 28.7 in
Table size: 1400 x 1600 mm / 55 x 47 in
Table load: 10 t / 22 000 lb
Spindle Taper: CAT 50
Spindle Revolutions: 3000 RPM
Control System: Fanuc 32i
Fanuc Spindle Motor Power: 22 kW / 30 HP
Outside Coolant: 6 bars 87 psi
Through Spindle Coolant: 20 bars 290 psi
Automatic tool change: for 40 tools
Chip conveyor
