GMW, TB 130 CNC, HORIZONTAL TABLE TYPE, BORING MILLS
  • Condition:New
  • Category:BORING MILLS
  • Type:HORIZONTAL TABLE TYPE
  • Manufacturer:GMW
  • Model:TB 130 CNC
  • YOM:-
  • Location:Germany, Ennepetal
  • Price:On request
  • Stock No:70085
  • Control:CNC
  • ID:AS21569
Description:
NEW MACHINE made in China. All important parts are made by western well known
companies. Control: Siemens 828D. Warranty and service is provided by
GMW-machines.de. Also as a ram type available with 130 mm or 160 mm spindle.
All axes could be chosen in other sizes as per customers requirements.
Specifications:
spindle diameter: 130 mm
x/y-travel: 3500/2500 mm
spindle stroke max. 800 mm
spindle taper: ISO 50
spindle turning speed range: 10-2000 U/min.
z-axis: 1500 mm
table surface area: 2000 x 1800 mm

-further information on request-
Dimensions:
5,9 x 3,5 x 3,7 m
Weight:
20000 kg
