CAPACITY (MILD STEEL): 16 GA.
BENDING LENGTH: 121"
LIFT OF BEAM (MAX.): 2-1/4"
FRONT TO REAR BEAM ADJUSTMENT: 1/2"
REVERSE BEND (MIN.): 1/4"
FLANGE IN CAPACITY MATERIAL (MIN.): 1"
DIMENSIONS (COUNTERWEIGHTS IN PLACE): 161" L X 53" W X 59-1/2" H
SHIPPING WEIGHT: 2,875 LBS.
EXPORT CRATE: 187 CU. FT.
STANDARD EQUIPMENT:
ROLLER-TYPE THRUST BEARINGS
THE UPPER LEAF ADJUSTMENT SCREWS PERMIT QUICK, ACCURATE ALIGNMENT
FOR DIFFERENT MATERIAL THICKNESS OR RADII.
LEVELING SCREWS AND LOCK NUTS ON THE PEDESTALS
JACK SCREWS AND TENSIONER BOLTS ON THE APRON
TRUSS RODS ON THE APRON, BASE AND UPPER LEAF
FULLY ADJUSTABLE COUNTER BALANCES TO FACILITATE THE
BENDING PROCESS.
REMOVABLE APRON ANGLE AND INSERT PERMIT 1/4" REVERSE BENDS IN
LIGHTER MATERIAL
