CAPACITY (MILD STEEL): 12 GA.
(STAINLESS STEEL): 16 GA.
BENDING LENGTH: 48 1/4"
LIFT OF BEAM (MAX.): 1 1/2"
FRONT TO REAR BEAM ADJUSTMENT: 1"
DEPTH OF BOX (MAX.): 4"
REVERSE BEND (MIN.) (ANGLE AND
INSERT REMOVED): 1/4"
FLANGE IN CAPACITY MATERIAL (MIN.): 1"
FINGER WIDTHS: 2, 3 AND 4"
DIMENSIONS (COUNTERWEIGHTS IN PLACE): 72" L X 36" W X 53" H
NET DIMENSIONS, (COUNTERWEIGHTS AND
HANDLES REMOVED): 65 1/2" L X 32" W X 47" H
SHIPPING WEIGHT: 1,330 LBS.
EXPORT CRATE: 79.5 CU. FT.
STANDARD FEATURES:
LEVELING SCREWS AND LOCK NUTS ON THE PEDESTALS
JACK SCREWS AND TENSIONER BOLTS ON THE APRON
TRUSS RODS ON THE APRON, BASE AND UPPER LEAF
FULLY ADJUSTABLE COUNTER BALANCES TO FACILITATE
THE BENDING PROCESS.
AMPLE CLAMPING AND NOSE BAR ADJUSTMENTS ALLOW FOR THE BEND RADIUS
NECESSARY FOR YOUR APPLICATION.
WELDED STEEL PLATE CONSTRUCTION AND HEAVY TRUSS RODS AND BRACES
PROVIDE STRENGTH AND RIGIDITY.
