Wheel diameter - max: 750 mm Wheel width: 200 mm module - Max: 10 Module - min: 1 Number of Teeth: 6 / 300 helix angle - max: 60 stroke: 15 / 240 mm length of roll of the table max:..... 432 mm table diameter: 500 mm Table bore: 90 mm workpiece weight: 800 kg min ram strokes /: 23.5-150 Rundvorschübe: 90-80 tilt: 0 - 60 Machine Weight: 5.0 t space requirement approx: 2.6 x 1 , 9 x 2.3 meters including accessories, overarm
