Stock-No. 1106-BO204
Type of machine Radial Drilling Machine
Make KOVOSVIT MAS
Type VR 4
Year of manufacture 1976
Type of control konventionell
Storage location Pagus NL. Jena Germany
Country of origin Czech Republic
Specifications:
Technical details
bore capacity in steel (diameter) 40 mm
arm length 1200 mm
workpiece height max. 1227 mm
surface area 1475 x 900 mm
no. of flutes 3
groove width 25/ 50 mm
spindle cone MORSE 4
number of spindle speeds 45- 2800 U/min
spindle headstock Bew.Arm : 945 mm
with vertical adjustment Arm 710 mm
spindle diameter 35 mm
bore depth 300 mm
total power requirement 3,0 kW
weight of the machine ca. 2800 kg
dimensions of the machine ca. 2290 x 910 x 2860 mm
