CNC Horizontal Borer Scharmann FB 180 with S/N: 76138026 Built: 1976. Modernized with CNC Control Philips 1990.
Spindle diameter 180 mm
Spindle nose diameter 280 mm
Ram size 400x400 mm
Spindle travel 750 mm
Ram travel 1000 mm
Ram + spindle travel 1750 mm
Spindle power 80 KW
X-travel 5869 mm
Y-travel 4479 mm
TABLE
No of T-slots 15
Table size 3000x4000 mm
Table positioning 0,001°
Cross travel 2000 mm
Table load 70 Tons
SPACE REQUIREMENTS
Length 10 640 mm
Width 4 370 mm
Height 8 100 mm
