Ocean Avenger II Beam Drill, Model MDL-1000/1B, s/n 50133, Siemens CNC Control (#1638)
Specifications:
#1638 Ocean Avenger II Beam Drill
Sn: 50133
Model: MDL-1000/1B
Mfg:
SPECIFICATIONS:
Maximum Machining Height/Width: 39.38”
Maximum Thickness: 6”
Minimum Thickness: 1/8”
Maximum Length Piece Part: Based on Table Length, 60’ Max
Max. “X” Axis: 120 ft/min
Max “Y” Axis: 120 ft/min
Motor Power: 20HP
Hydraulic Pressure: 1750 PSI
Available Clamping Force: 2,945-6,872 Lbs
Weight: 17,250 Lbs
Number of Rill Spindles: 1
Spindle Speed: 200 RPM to 850 RPM
Drill Diameter: 5/16” to 1-9/16”
EQUIPPED WITH:
Siemens CNC Control
Machine Condition: Very Good
Machine Location: Whitehall PA
