Boring spindle 80 mm
Facing slide of faceplate 125 mm
Table surface 1000x1000 mm
Spindle taper ISO 40
Headstroke (W) 500 mm
Boring spindle stroke (Y) 800 mm
Longitudinal table stroke (Z) 1000 mm
Cross table stroke (X) 1000 mm
Spindle speed range 20-1600 rpm
Faceplate speed range 6,3-200 rpm
Feeding range
- headstroke 1,26-2000 mm/min
- boring spindle 1,26-2000 mm/min
- facing slide of faceplate 0,5-800 mm/min
Main motor power 6,5 kW
Approximate dimensions, LxWxH 4520x2390x2585 mm
Weight 8500 kg
