Maximum Diameter of Drilling hole：50mm
Dimension：2500*1066*2605mm
Distance from centeral line of spindle to generatrix of column:360-1600mm
Distance from spindle nose to baseplate working surface:315-1210mm
Spindle taper: Morse No.5
Spindle travle: 315mm
Drilling Depth of dial per round ：123mm
Spindle speed Grade and spindle speed Scope (Forward Moving) Grade 16,25-2000rpm
feed grade and range：Grade 16，0.04-3.2mm/r
main motor power:4kw
weight machie:4000kg
