Outreach - 330 mm
Drilling capacity in steel - ST 60 40 mm
Drilling capacity in steel - ST 60 50 mm
Spindle thread - MK 4
Drill spindle - 200 mm
Speed - 100-1280 U/min
3 feeds - 0,1-0,36 mm/U
Table with 2 T-slots - 740x590 mm
Distance table to spindle - 780 mm
Spindle-foot plate distance - 1250 mm
Height adjustable via rack with hand crank
lighting
Power - 400 V / 2,3 / 3,4 kW
LxWxH - 1150x750x2150 mm
Weight - 750 kg
without thread cutting operation!
