XY-axis travel mm: 800 x 600 mm UV-axis travel: 150 x 150 mm Z axis travel: 600 mm max. Workpiece dimensions in mm: 1300 x 1000 x 595 max. Workpiece weight: 4000 mm Distance from floor to table: 900 controlled axes: 5 (X, Y, U, V, Z) Increments: 0.5 mm wire diameter: 0.10 to 0.33 max. Coils of wire recording kg 45 kg = Jumbo Feeder
