4.1 Nominal capacity 25Mpa 16 MN
30Mpa 20 MN
4.2 Plunger diameter of main cylinder 920 mm
4.3 Return capacity 2000 kN
4.4 Daylight 3100 mm
4.5 Max. slider working stroke 1400 mm
4.6 Center distance between columns 2400×1500 mm
4.7 Size of movable working table 4000×1500mm
4.8 Capacity of movable working table 630 kN
4.9 Stroke of movable working table 2000 mm
4.10 Slider speed
speed at approach 250 mm/s
working speed 45 mm/s
return speed 250 mm/s
