C86 series Hydraulic Closed Die Forging Hammers are desired for general forging works, for example automobile forgings , airplane forgings, motorcycle forgings, hardware forgings, hand tools blank forgings etc.
Specifications:
Hydraulic Closed Die Forging Hammer
Electric hydraulic die forging hammer is mainly applied in batches production of all kinds of die forgings,such as automobile forgings,tractor forgings,agricultural equipment forgings, oil and gas industry die forgings, electrical power station die forgings and industrial forgings.
Hydraulic Closed Die Forging Hammer can save about 80-90% energy than steam hammer which is the common understanding of personage of machinery industry.
Features of Hydraulic Closed Die Forging Hammer:
1. Energy saving and environmental protection.
2. High speed and high efficiency blowing increases production efficiency.
3. 'X' type guide rails guarantee precision forging and strong anti deviated loading ability.
4. Auto lubricating of guide rails.
5. PLC control, immediately starting and immediately apply into forging production.
6. Safety and easy operating by foot pedal or hand lever.
7. High efficiency cooling for hydraulic oil.
Parameters of Hydraulic Closed Die Forging Hammer:
Model: C86-150 (6T)
Max hitting energy (KJ) : 150
Weight of falling parts (kg) : 7000
Max stroke (mm) : 1350
Hit frequency (min-1) : 45-55
Main motor power (kw) : 55
Number of motor (set) : 5
Electric-cooler type (type) : YLD1200
Electric-cooler capacity (Kcal/h) : 120000
Electric-cooler power (KW) : 60
Guide space (mm) : 800
Min die height (mm) : 430
Machine outside size (mm) : 3800*2300*9200
Oil tank outside size (mm) : 4500*2000*1600
