Maximum force 1600 ton
Slider stroke length 300 mm
Slider strokes per minute 85
Maximum distance between table and slider
(in lower position of slider) 660 mm
Size of adjustment of distance between a table and slider 10 mm
Size of a course of the top pusher 40 mm
Size of a course of the bottom pusher 32 mm
Table overall dimensions:
- from left to right 1080 mm
- from front to rear 1200 mm
Slider overall dimensions:
- from left to right 894 mm
- from front to rear 944 mm
