- Technical Data - Max. Workpiece: 450 mm max. - Milling width (spur): 500 mm max. - Teilrad: 625 mm max. - Copying device for Convex and late withdrawal - Module: 10 mm - table-/ 420 mm - Table Bore: 100 mm - adjustment of the spindle: 200 mm - Distance cutter - workpiece axis: 30 - 300 mm - turning length: 850 mm - Distance table to center spindle: 475 mm - max. Cutter: 192 mm - max. Cutter length: 250 mm - arbor-taper: 40 min 320 U / MK 5 - milling head swivel: tool spindle speed (stepless) - 240 - Feed in 2 directions. - Axial feed (continuous): 212 min 0.21 mm / min. - Centrifugal advance (continuously): 0.70 min 14 mm / min. - Tangentialvorschub (infinitely) min / 0.02 53 mm / min. - Feed per revolution of the workpiece: 0.10 10 mm / WU - performance of Leonard ruleset: 380V +50 Hz + 8.5 kW - total power requirement: about 18 KW - electric cutting oil coolant pump: 150 l / min. - Weight of machine: 9500 kg - space LxWxH: L x W x H 4.25 mx 3.88 mx 3.2 m - Accessories - arbors - set of change gears

-
