Max. gear wheel diameter: 800 mm
Max. module: 10 mm
Table diameter: 800 mm
Min. number of teeth: 10
Inclination angle of the head: +/- 60 degrees
Hob arbor taper: Morse 5
Hob cutter speed range: 50 - 300 RPM
Max. axial travel: 450 mm
Max. tangential travel of the hob: 150 mm
Working feeds:
- radial: 0,63 - 4,5 mm/rot
- axial: 0,1 - 2,2 mm/rot
- tangential: 0,1 - 10 mm/rot
Main motor power: 7,5 kW
Net weight of the machine: 11 to
