Diameters of cylindrical gears to be cut 200...2000mm
Maximum hob slide vertical travel 900mm
Maximum module of gears to be cut (not less than), mm:
- with hob 20
- with disk-type cutter 25
Maximum tooth helix angle of gears to be cut ± 45 deg.
Maximum mass of workpiece accommodated 20000kg
