Gear Hobber 5A342П (2000mm Modul 24mm)

Max. diameter gears cut: 2000 mm
Max. vertical moving of milling support: 900 mm
Max. module of processed wheel (not less):
-Worm mill: 20
-Disk mill: 25
-Manual mill: 30
Table diameter: 1800 mm
Max. work-piece weight: 20 tons
Max. corner: +/- 45 degree
Diameter of installed worm mills: 300...500 mm
Amount of cutting teeths: 10...1800
Spindle speed: 8...125 rpm
Electricity: 50 Hz, 380 V
Main motor power: 20 kW
Overall dimensions (LxWxH): 8600x4440x3700 mm
Machine weight: 32040 kg
