Max. wheel diameter, mm 1000
Max. work piece diameter with tail-stock, mm 750
Gear width, mm 400
Distance between hob axis and table axes, mm 50...720
Distance between hob axis and table surface, mm 280...740
Table diameter, mm 750
Spindle speed range, rpm 20...125
Spindle speeds, qty 9
Min. processed wheel teeth, qty 12
Max. module 10
Max. gear teeth angle, degree 36
Table opening diameter, mm 100
Voltage, V 380
Frequency, Hz 50
Main motor power, kW 7,5
Machine dimensions, mm 3100 x 1900 x 2500
Machine weight, kg 8700
