Make: Karstens Type: K56 Year: 1991 Built: 1000 Distance between centers: 1000 mm Grinding length: 1000 mm Height: 180 mm Schleifschleiben: 500 mm disc assembly: right spindle: 60 mm Power: 7.5 kW cover width: 100 mm circumferential speed: 35 m / s workhead determinable spindle Recording: MK 4 tailstock taper: MK 4 Control: CNC NUM 760 R data transfer and interactive programming Extras: Additional equipment: machine base slide drives EL-hand wheel to move the axes XZB in the setting wheel head: INNER LOOP: for grinding length 1000 and 1500 mm internal grinding device: power: 3 kW spindle 80 mm spacer rings 60 mm, coolant supply factory floor headstock clamping tools clamping tube with accessories for tensioning casing plates, Spindelzentrierung 63 mm chuck 160 mm Spindelzentrierung 63 mm pliers quick voltage for workhead MK 4, including tension tube and forceps use measurement control system for mounting a grinding table instrument (pneumatic feed cylinder) Equipment for production of another table grinding instrument (pneumatic feed cylinder) Marposs - Messteürungen E5 amplifier with probe 3 for closed Micromar diameter 3-120 mm + / - 0.5 mym, key arms 3-60 mm Positionar passive measuring, in combination with the common amplifier E5 You [...Technical data truncated]
