4" Dia. Spindle WITH #50 SPINDLE TAPER
48" x 86" Table
One piece castiron 4 Bedway
26 Spindle speeds 9-1200 RPM
Spindle traverse 36"
Headstock vertical travel 60"
Table working surface 48" x 86"
Table cross travel 76"
Heidenhain DRO on Cross
Saddle travel 76"
81 Feeds .0001-1.038 IPR
EQUIPPED WITH:
pendant control
Power rapid traverse
Built-in 4-way bed
20 H.P.
Auto Lube on saddle
Some Tooling
Coolant System
Approx. weight: 41,500 lbs

Dimensions: 18’4"L x 11' 6"W x 10’9"H

OPTIONAL TOOLING AVAILABLE
ROTARY TABLE
ANGLE PLATES
ADDITIONAL TOOL HOLDERS

7700 LBS.
