Centre height 100 mm

Distance between centres 400 mm

Max.Longitudinal travel 420 mm

Grinding wheel diameter 350 mm

Grinding wheel width 50 mm

Table load max. 20 kg

Workpiece weight on centres max. 20 kg

Grinding wheel speeds:

Peripheral speed 30 m/s

Angular displacement 15/30°

Work piece spindle head speeds:

from 30 rpm

up to 1200 rpm

Spindle taper 4 MT

Taper in tailstock 2 MT

Table speed:

stepless

from 100 mm/min

up to 3500 mm/min

Voltage 50Hz 3x 380 Volt

External Grinding wheel motor 3 kW

Internal Grinding wheel motor 1.1 kW

Total power requirde 10 kVA

Machine's weight about 1900 kg

Overall dimensions machine(LxWxH): 3165x2800x1800 mm

-
