under power

1991 SMTW 14.2" x 59" Cylindrical Grinder Model - MB1332BX1500 S/N - 54

SPECIFICATIONS:
Max Swing Over Table - 14.2"
Distance Between Centers - 59"
Traverse Speed - 2" to 160 " IPM
Table Swivels, Clockwise/CCW - 3 Deg/4 Deg
Standard Grinding Wheel Size - 24" O.D. x 3" W x 12" Hole
Grinding Wheel Spindle Speed - 1,130 RPM
Automatic Infeed Per Table Reversal - Yes
Minimum Auto Infeed Increment - .00002"
Auto :lunge Infeed - Yes
Plunge Infeed Speed - 2" to 60" IPM
Rapid Hydraulic Infeed Stroke - 2"
Max. Travel of Leadscrew - 9"
Travel Per Rev. of Handwheel - 0.04"
Travel Per Div. of Handwheel - 0.0002"
Workhead Spindle Speeds (6 Speeds) - 32 to 312 RPM
Workhead Taper - #4 MT or #5 MT
Tailstock Taper - #4 MT
Tailstock Spindle Travel - 1.2"
Approximate Machine Weight - 9,460 lbs.

EQUIPPED WITH:
Hydro-Dynamic Wheelhead Spindle Bearings
Hydraulic Table Traverse
Automatic Infeed @ Table Reversal
Auto Plunge Infeed
Hydraulic Rapid Wheelhead Advance/Retraction
"Dead" Headstock Spindle
External Coolant Tank & Pump
15 HP 3/60/230-640 Volt Wheelhead Drive Motor

INSPECT UNDER POWER ORIGINAL PAINT - EXCEPTIONAL APPEARANCE & CONDITION

PRICE: $POR

E-Mail: bidspec@bidspecialists.com
