Gear diameter max: 1200 mm, stroke length max: 650 mm, number of teeth: 999, module max: 25 wheelhead 1 Engine Power: 15 kW, grinding wheel diameter: 180/300 mm, speed max: 1000 - 5000 r / min. Wheelhead 2 Engine power: 15 kW, grinding wheel diameter 125/200 mm, max speed: 2000 - 8000 U / min. Arrester: distance RT - peak max: 500 mm tailstock quill 630 mm, quill 116 mm, work table: Round Table, Table diameter: 500 mm, bore: 370/260 mm Table load: 3500 kg Accessories: Lynette, brace, grinding wheels, grinding wheels - recordings , stripper, pinch rolls, manual weight: about 19,000 kg Power: 70 KVA machines - Dimensions: 3425 x 2330 x 3735 mm Control: CNC Oerlikon
