Grinding depht 400 mm
Diam holes, 200 mm
Max length 200 mm, the details
Min.diametr holes, 20 mm
The distance from the table to the spindle axis, 285 mm
headstock-angle 45 °
Speed automatic transverse feed-0 ,0004-4 mm/min.
The speed of the table-0,1-7 m/min.
movement of the table, 560 mm
Spindle Speed-60-1200 rpm.
The speed of rotation of the grinding spindle-5000-2000 rpm
Power 4,4 kw.
Grinding Wheels:
Outer Ø 20-125 mm
Dimensions 2700x2085x1850 mm
Weight 4500 kg

-
