x-travel 650 mm
y-travel 450 mm
feed range 0 - 1500 mm/min
table surface area 770 x 630 mm
table load capacity 500 kg
distance between columns 750 mm
concentricity - max to be ground 16 °
planetary speed 5-250 U/min
electrics - voltage/frequency 440/60 V/Hz
vertical adjustment of the crossrail 500 mm
total power requirement 8 kW
weight of the machine ca. 4,5 t
dimensions of the machine ca. 4 x 3,6 x 3,2 m
