Abrasive O.D. 30”
Useable abrasive thickness: 3”
Spindle drive motors: (40HP 220/440 3ph, 60hz) currently wired for 440 volt
Machine mounted main operator’s pushbutton station
Power operated rapid traverse and pushbutton controlled compensating infeed units
Power operated radial arm dresser
(2) Abrasive steel mounting plates
Coolant through spindles for connection to a central system
Rotary Carrier fixture mounted on the front knee
Approximate floor space: 114” x 146”, weight 20,000 lbs.
Trabon grease lube system
Two-door electrical panel with Modicon 484 controller and J474 slave communication
Rear sump tank
Setup stairs
Gauge fixture with gauge heads but no gauge monitor
