Clamping length mm 625 max
Grinding slide stroke mm 500 max
Grinding speed mm/min 25 - 2500
Reversal stroke speed m/min 6
Swivel of grinding head degree 0 - 45
Gash lead, infinitely variable from 12” -
Grinding depth mm 60
Vertical adjustment of grinding spindle mm 90
Max. grinding wheel dia mm 300
Min. grinding wheel dia mm 100
Distance between vertical grinding spindle and center mm 75 - 300
Center distance over floor mm 950
Mounting lever of main spindle ISO 50
Max. workpiece dia mm 300
Pre-selectable spindle settings 0 - 99
Lifting stroke, infinitely variable mm 0 - 50
Hydraulic motor drive for grinding spindle KW 5.5
Hydraulic motor drive for grinding wheel head KW 1.5
Coolant pump KW 0.68
Redial rapid adjustment KW 0.18
Oil dust absorber KW 0.75
Total Power Supply KVA 15

-
