Machine Only Used For One Job, Like New, Machine Is Already Dismantled & Ready For Your Inspection
Specifications:
Specification:
Model........................................... ACC140-330
Spindle Diameter................................ 139.7MM
Cross Travel(X Axis)............................ 8966.19MM
Vertical Travel(Y Axis)......................... 3022.6MM
Spindle Travel(Z Axis).......................... 812.8MM
Rotary Table.................................... 2489.2MM x 2006.6MM
Rotary Table Travel............................. 990.59MM
Spindle Taper................................... ISO 50 Draw Bar
Spindle Speeds.................................. 5 – 700 RPM
Max Load On Rotary Table........................ 30 Tons
Quill Diameter.................................. 317.5MM
Quill Travel.................................... 406.4MM
Motor........................................... 22 KW
Volts........................................... 400 V
Approximate Weight.............................. 52,000 KG
Equipped With:
4 Axis Heidenhain Digital Readout, Pendant Control, Chip Conveyor,
Heavy Duty Rotary Table, NO FLOOR PLATES (Might Be Able To Get If Needed)
Y Axis Ball Screwed, X Axis Rack & Pinion Lock Type,
