3 HP(V3) spindle motor.
Front mount spindle with run-out within 0.00008".
Table overall flatness within 0.00012".
Wheel guard with capacity for 8" wheel.
Longitudinal table stroke is 20".
Continuous loop-cog timing belt system.
Crossfeed lock.
Adjustable longitudinal table stops.
Meehanite casted saddle with Double-V Turcite ways.
Safety 24 volt circuit control.
Push button manual starter with overload protection.
Distance between Double-V is 19.6" apart.
The width of machine base is 22".
FC 25 machine base weighs more than 1,584 lbs.
Maximum work load at 320 lbs.
