Installed on basic 1985, excellent working condition,conservation.
Specifications:
Maximum working piece width: 2500 mm
Working width on table: 2240 mm
Working length on table: 6500 mm
Max.workpiece height 1450 mm
Size of Table: 2200x6200 mm
Max. Loading on table: 12 ton
Distance between columns: 2680 mm
Travel of the grind.heads over the saddle min/max 450...2500mm
Grinding disk dimensions: 630 x 100 x 305 mm
Slew angle of the grinding head,deg +/- 90
Shaft speed: 900 rot./ min.
Power of main drive motor: 20 kW
Fixing surface: 2200 x 6500 mm
Machine total length: 13.800 mm // width: 7.600 mm / height: 5.000 mm
Weight of machine: 150 ton
