Chuck: 20" Dia., Electro-Magnetic
Maximum Swing Inside Water Guards: 21"
Maximum Height Under Wheel: 12"
Wheel Speed: 1200 RPM
Cylinder Type Grinding Wheel: 11" x 9" x 5" High
Variable Table Speeds: 15 to 75 RPM
Variable Servo Vertical Down Feed: .0001 to .100 IPM
Digital Control with Servo Motor for Feed and Traverse, Fine Feed, Auto Spark Out, Digital Readout
15 HP Spindle Motor
Variable Power D.C. Chuck Control
Trabon Automatic Lubrication System
Floor Space: 4' x 7' x 8' High
Weight, Approx.: 8,000#
