Specifications-Subject to Verification
66" Magnetic Chuck, 5/8" Chuck Life
84" Swing Inside Water Guards
36" Vertical Height
200 HP Main Grinding Spindle
36" Diameter Grinding Wheel
Cortland Style 8 Segment Grinding Chuck
5.6 to 20.1 Chuck Rotation Speeds RPM
.004 to .080 Down Feed Rates IPM (Pick-Feed)
One Shot Lube System On Head
Bijur Oil Lube System (Base Ways)
10,000 Lb. Approximate Table Load
Machine Weight Approximately 70,000 Lbs.
