84" Magnetic Chuck
Approximately .510-.515" "Chuck Life"
87" Swing Inside Water Guards
40" Maximum Height Under Wheel
42" Grinding Wheel
250 HP Main Spindle Drive,240/480 Volt, Wired 480 Volt
(4) Table Speeds of 3, 4.8, 7.8, 11.9 RPM
.008" to .096" Per/Min Variable Vertical Downfeeds
Equipped With:
Power Rapid Raise and Lowering of Head
Coolant System
Hardened Bed Ways
Water Guards
Oil Lubrication
Automatic Lubrication
Grinder Dimensions (Aprox.) 240.57" L x 108" W x 160" H
Coolant Dimensions (Approx.) 264" L x 96" D x 105" H
Weight Approximately: 75,000 Lbs.
Replacement cost is over $650,000
Priced As Rebuilt
See full rebuild specs at www.fpmiller.com
