SPECIFICATIONS:
Minimum table stroke:.4”
Maximum grinding stoke:40”
Nominal grinding length:36”
Maximum grinding width:17”
Nominal grinding width:16”
Table size:16” x 36”
Max. work height Under 14” Dia. Wheel:18”
Max. work height Under 16” Dia. Wheel:16”
Wheel size:16” Dia. x 3” Width
Infinitely variable table speed range:.4 to 100 IPM
Infinitely variable wheel speeds:100 to 3000 RPM
Max. reciprocation rate of table:200 S.P.M.
Continuous feed rate:0 to 225 IPM
Incremental feed, minimum:.000010”
Incremental feed, maximum:1”
Vertical feed of wheel head:19 ¼”
Rapid traverse rate of wheel head:0 to 40 IPM
EQUIPPED WITH:
Ball screw drives for cross and wheel slides, 14”x32” electromagnetic chuck w/ control
Dresser, Coolant filtration System, Coolant Splash enclosure, Wheel mount, Automatic lubrication,
Integral cartridge type Spindle drive, 15 H.P. DC Variable speed Spindle drive, Allen Bradley Series 9 CNC control with CRT, port, spare parts
Approx. weight: 14,000 lbs.
Dimensions: 142”L x 124”FB x 105”High
Machine Condition:Excellent
Machine Location:Wilmington, DE
