STANDARD SPECIFICATIONS
Component size (min/max)………………………………. 0.059” – 4.7”
Maximum infeed grinding length………………………… 10”
Grinding wheel dimensions, OD x width x bore...……….. 24” x 10” x 12”
Grinding wheel peripheral speed…………………………. 35 / 50 m/s
Regulating wheel dimensions, OD x width x bore……….. 14” x 10” x 5”
Regulating wheel speed…………………………………… 5-300 min-1
Dressing speed…………………………………………….. 300 min-1
Main motor………………………………………………... 22 / 30 kW
Servo motor AC regulating wheel………………………… 6 / 12 Nm
Floor to spindle center height……………………………... 44”
Net weight………………………………………………… 14300 lbs.
Gross weight………………………………………………. >15400 lbs.
