12" x 24" Okamoto Model ACC-124DX Programmable High-Precision Surface Grinder
Specifications:
EQUIPPED WITH:
"DX" Programmable Electronic Auto Incremental Downfeed: Servo Driven Downfeed, Auto Incremental Downfeed For Both Surface & Plunge Operations, Dual Rate Auto Downfeed with Rough & Fine Feed Selections. Digital Display For Vertical and Cross Feed Axis Position Display. Sparkout Passes (0 To 5) W/Auto Table Park At Completion Of Grind Cycle, Electronic Handwheel For Manual Vertical Movement W/Each Grad. Equivalent To .00001", .0001" Or .001", Power Rapid Wheel Positioning.
Over the Wheel Hydraulic Dresser with Sparkout and Dress Compensation. Hydraulic Table Traverse. Automatic Crossfeed. 12"x 24" Electro-Magnetic Chuck. OS Walker Variable Hold Neutrofier Control & Demagnetizer. Coolant System with Magnetic Separator. Wheel Balancer with Arbor. (2) Spare Wheel Mounts.
SPECIFICATIONS:
Nominal Grinding Capacity 12" x 24"
Maximum Height Under 12" Wheel 13.6"
Table Speed, Infinitely Variable up to 82 FPM
Max. Longitudinal Table Movement 29.5"
Auto Cross Feed Increment 0.002" To .80"
Auto Continuous Crossfeed 4 - 40 IPM
Crossfeed, Manual, Hand Feed Per Rev 0.25"
Grad. Of Handwheel 0.001"
Max. Crossfeed 13.4"
Auto Incremental Downfeed Increments 0.00005" To .0015"
Power Rapid Wheel Positioning Rate 16 IPM
Spindle Motor 5 HP
Wheel Size 12" X 1.5" X 5"
