Stock-No. 1106-SF256
Type of machine Surface Grinding Machine
Make ZIERSCH & BALDRUSCH
Type Starline 500 CNC
Year of manufacture 1999
Type of control CNC
Storage location Pagus NL. Jena Deutschland
Country of origin Germany
Specifications:
Technical details
grinding width 250 mm
workpiece height 380 mm
Sinumerik
max. dia. of grinding wheel 300 mm
weight 4000 kg
total power requirement 12,5 kW
grinding wheels Ø 400 mm
max. width of grinding wheel 100 mm
grinding wheel hole diameter 127 mm
turning speeds 470 - 12030 1/min
x-axis 600 mm
y-axis 300 mm
z-axis 250 mm
grinding range 450 x 200 mm
distance spindle nose and table 500 mm
table load 250 kg
dimensions of the machine ca. 2600 x 2100 x 2400 mm
coolant
switchgear cabinet 1300 x 800 x 2000 mm
hydraulical unit: 450 x 350 x 500 mm
