grinding length: 100 mm
distance between centers: 860 mm
threat diameter: min: 14 mm - max: 250 mm
max orientation angle: 40 degrees
grinding wheel:
diameter: min. 8 mm, max. 100 mm
width: min. 3.5 mm, max. 24 mm
grinding wheel speed
from 4800 rpm till 11000 rpm
from 11600 rpm till 27000 rpm
parts-holder spindle speeds
variable 0.40 rpm to 160 rpm
power required 50 Hz - 3x 380 Volt - 16 kVA
dimensions:
length: 1855 mm - width: 3500 mm - height: 1700 mm
weight: 4850 kg
equipment
coolant, grinding oil cleaning attachment
gears, protective cover, oil cooler
