Grinding diameter - max. 250 mm grinding length 450 mm workpiece length 600 mm table movement along 500 mm table - adjustable 0 - 90 degrees cone Uni-5 Morse taper tailstock workhead Morse2 grinding diameter - max. 160 mm Speed range 2200/3500/5200 rev / min hydraulic power unit 130 kg total power requirement 1,8 kW Machine weight 900 kg dimensions of 1300 x 2000 x 1620 mm optional accessories (optional, not included) - spiral grinding device with guide plate (300, - Euro net) - External cylindrical grinding device with workpiece drive motor and three-jaw chuck (300, - ⬠net) - permanent magnet table (150, - ⬠net) - Universalaufspannkopf with Qürsupport (150, - ⬠net)
